Inverter Model Numbers
The model number of the Inverter on the nameplate indicates the specification, voltage class, and maximum
motor capacity of the Inverter in alphanumeric codes.
Fig 1.2 Inverter Model Numbers
Inverter Specifications
The Inverter specifications (“SPEC”) on the nameplate indicate the voltage class, maximum motor capacity,
the protective structure, and the revision of the Inverter in alphanumeric codes.
Fig 1.3 Inverter Specifications
 Inverter Software Version
The Inverter software version can be read out from the monitor parameter U1-14. The parameter shows the
last four digits of the software number (e.g. display is “4020” for the software version VSF104020).
IMPORTAN
T
This manual describes the functionality of the inverter software version VSF104012 (Standard
Inverter) and VSF104020 (Safety Inverter).
Older software versions do not support all described functions. Check the software version before
starting to work with this manual.
CIMR – F7 Z 2 0 P4
Inverter
Varispeed F7
No.
Z
Specification
OYMC European. Std.
No.
Voltage Class
2
4
AC Input, 3-phase, 200 V
AC Input, 3-phase, 400 V
No.
Max. Motor Capacity
0P4
0.55 kW
0P7
0.75 kW
to
to
300
300 kW
“P” Indicates the decimal point.
40P41B
Revision / Version
B
C
Standard Inverter
Safety Inverter
Voltage Class
2
4
200 V
400 V
Max. Motor Power
0P4
0P7
to
300
0.75 kW
to
300 kW
0.55 kW
Protection
0
1
IP00
IP20
