Comparing Inverter Parameters and Digital Operator Parameter Set Values (VERIFY)
To compare Inverter parameters and Digital Operator parameter set values, use the following method.
If an fault is displayed, press any key to cancel the fault display and return to the o3-01 display. Refer to
page 7-18, Digital Operator Copy Function Faults for corrective actions.
Step
No.
Explanation Digital Operator Display
1 Press the MENU Key. and select advanced programming mode.
2 Press the DATA/ENTER Key.
3
Press the Increment and Decrement Key until the parameter o3-01 is dis-
played (Copy Function Selection).
4 Press the DATA/ENTER Key and select the function setting display.
5 Change the set value to 3 using the Increment Key.
6
Set the changed data using the DATA/ENTER Key. The VERIFY function
will start.
7
If the VERIFY function ends normally, “End” is displayed on the Digital
Operator.
8 The display returns to o3-01 when a key is pressed.
INFO
When using the copy function, check that the following settings are the same between the Inverter data
and the Digital Operator data.
• Inverter product and type
• Software number
• Inverter capacity and voltage class
• Control method
** Main Menu **
-ADV-
Programming
Initialization
-ADV-
A1 - 00 = 1
Select Language
COPY Function
-ADV-
o3
- 01=0
Copy Funtion Sel
Copy Function Sel
-ADV-
o3-01= 0
COPY SELECT
*0*
Copy Funtion Sel
-ADV-
o3-01= 3
*0*
OP INV VERIFY
VERIFY
-ADV-
DATA VERIFYING
VERIFY
-ADV-
VERIFY COMPLETE
Copy Function Sel
-ADV-
o3
-
01 = 0
COPY SELECT
*0*
