FRONT SUSPENSION
Name Torque in Nm
Fixing screw for pumping elements to lower fork plate 20 ÷ 25
Front wheel axle 45 ÷ 50
Fork leg screw 6 ÷ 7
front mudguard to plate fixing screw 4.5 ÷ 7
Fixing screw for mudguard plate to fork 9 ÷ 11
FRONT BRAKE
Name Torque in Nm
Brake fluid pump-hose fitting 16 ÷ 20
Brake fluid pipe-calliper fitting 16 ÷ 20
Calliper to fork tightening screw 20 ÷ 25
Disc tightening screw (°) 5 - 6
Oil bleed screw 12 - 16
Pad fastening pin 19.6 ÷ 24.5
REAR SUSPENSION
Name Torque in Nm
Left lower shock absorber support bolt 20 ÷ 25
Upper shock absorber clamp 33 ÷ 41
Lower shock absorber clamp 33 ÷ 41
Rear wheel axle 104 ÷ 126
Fixing screw for wheel rim to hub 34 ÷ 38
Muffler support arm to engine screws (*) 20 ÷ 25
REAR BRAKE
Name
Torque in Nm
Brake fluid pump-hose fitting 16 ÷ 20
Brake fluid pipe-calliper fitting 16 ÷ 20
Flexible/ rigid oil pipe coupling 9 ÷ 11
Rear disc tightening bolt 11 ÷ 13
Oil bleed screw 12 - 16
Screw tightening calliper to the support 20 ÷ 25
Screw fixing rear brake calliper support to engine 20 ÷ 25
Pad fastening pin 20 ÷ 25
MUFFLER
Name
Torque in Nm
Screw fixing manifold to muffler 15.5 ÷ 18.5
Muffler heat guard fixing screw 5 - 6
Exhaust fumes inlet screw 22 ÷ 26
Screw fixing muffler support arm to crankcase 33 ÷ 41
Nuts fixing muffler to support arm 27 ÷ 30
Nut fixing muffler to cylinder head 16 ÷ 18
LUBRICATION
Name
Torque in Nm
Hub oil drainage plug 15 ÷ 17
Oil filter on crankcase fitting 27 ÷ 33
Engine oil drainage plug/mesh filter 24 ÷ 30
Oil filter 4 ÷ 6
Oil pump cover screws 0.7 ÷ 0.9
Screws fixing oil pump to crankcase 5 - 6
Oil pump control crown screw 10 ÷ 14
Oil pump cover plate screws 4 ÷ 6
Oil sump screws 10 ÷ 14
Minimum oil pressure sensor 12 ÷ 14
Carnaby 125 - 200 Characteristics
CHAR - 15
