Removal
- Remove the fork
- Check that the upper ball bearing and the seat of
the lower roller bearings do not show signs of wear
or pricking.
In case of replacement, proceed as follows:
- Using a punch to remove the bearings, insert it
from the bottom and remove the ball bearing
above the headstock. Then remove the lower seat
of the roller bearing by inserting the punch from the
top of the headstock.
N.B.
ONLY REMOVE THE UPPER BALL BEARING IF YOU
REALLY NEED TO.
Specific tooling
020004Y Punch for removing fifth wheels from
headstock
See also
Removal
Refitting
Using the appropriate tool, refit the upper ball bear-
ing and the seat of the lower roller bearings on the
headstock as described below:
- Place a new ball bearing on the headstock and a
roller bearing seat on the lower part.
- Insert the tie rod screw of the appropriate tool
fitted out with the adaptors for planting the bearing
and seat it in the headstock as in the photograph.
- Using two 24 mm wrenches, tighten the screw
until the seat and the bearing are fully set in place.
N.B.
ALWAYS USE A NEW BEARING AND A NEW SEAT.
Specific tooling
001330Y Tool for fitting steering seats
Rear
Carnaby 125 - 200 Suspensions
SUSP - 207
