Removing the rear wheel
- Remove the exhaust silencer.
- Unscrew the shock absorber lower clamp and
rotate the shock absorber towards the scooter rear
part.
- Remove the cotter pin and the cap.
- Loosen the nut and collect the spacer.
- Remove the two screws fixing the right shock ab-
sorber support bracket and remove the bracket.
Suspensions Carnaby 125 - 200
SUSP - 208
