Dimensions and mass
WEIGHTS AND DIMENSIONS 125
Specification
Desc./Quantity
Kerb weight 154 ± 5 kg
Maximum weight allowed 350 kg
Overall height 1.175 mm
Width 755 mm
Wheelbase 1.370 mm
Length 2,025 mm
WEIGHTS AND DIMENSIONS 200
Specification
Desc./Quantity
Kerb weight 154 ± 5 kg
Maximum weight allowed 350 kg
Overall height 1.175 mm
Width 755 mm
Wheelbase 1.370 mm
Length 2,025 mm
Engine
ENGINE 125
Specification
Desc./Quantity
Type Single-cylinder, 4-stroke
Cubic capacity 124 cm³
Bore x stroke 57.0 x 48.6 mm
Compression ratio 12 ± 0.5: 1
Engine idle speed 1650 ± 100 rpm
Timing system 4 valves, single overhead camshaft, chain-driven.
Valve clearance Inlet: 0.10 mm Outlet: 0.15 mm
Max. Power 11 kW at 9,750 rpm
MAX. torque 12 Nm at 8,000 rpm
Carnaby 125 - 200 Characteristics
CHAR - 9
