Driven pulley
DRIVEN PULLEY
Code
Action Duration
1 001022 Clutch - Replacement
2 003072 Clutch unit - Wear check
3 001012 Driven pulley - Service
4 001110 Driven pulley - Replacement
5 001155 Clutch bell housing - Replacement
Time Carnaby 125 - 200
TIME - 270
