Front
Removing the front wheel
- Remove the front calliper.
- Loosen the wheel axle lock-nut.
- Loosen the two wheel axle safety screws on the fork leg, on the brake calliper side.
- Pull out the wheel axle.
Front wheel hub overhaul
Check that the wheel bearings do not show signs
of wear.
If you have to replace the wheel bearings, proceed
as follows:
- Remove the plastic cover on the tone wheel side
to avoid damage by loosening the 5 fixing screws.
- Remove the two bearings on the odometer drive
side using the pliers 14 or 34 and the bell detail 9.
- Remove the internal spacer.
Suspensions Carnaby 125 - 200
SUSP - 192
