- Remove the external screw and the spoiler.
Fuel tank
- Remove the helmet compartment.
N.B.
THIS OPERATION SHOULD PREFERABLY BE PERFORMED WITH THE TANK EMPTY.
- Undo the two screws, on the rear wheel housing,
connecting the tank to the frame and collect the
washer.
- Disconnect the connector of the probe checking
fuel level.
- Disconnect the overflow pipe.
Carnaby 125 - 200 Chassis
CHAS - 253
