Fuel pump
FUEL PUMP
Code
Action Duration
1 004073 Fuel pump - Replacement
2 004137 Carburettor pump hose - Replace-
ment
3 004089 Tank-pump hose - Replacement
4 004072 Fuel filter - Replacement
Carnaby 125 - 200 Time
TIME - 305
