PIAGGIO Carnaby 125 - Side Fairings

- Undo the four centre screws.
- Operating on both sides, undo the two screws on
the lower part.
- Remove the footrest.
Side fairings
- Remove the cover by undoing the two screws.
- Operating on both sides, undo the four screws
and remove the spark plug inspection cover pulling
it upwards.
Carnaby 125 - 200 Chassis
CHAS - 249
