Renesas R8C/20 User Manual

Rev.2.00 Aug 27, 2008 Page 1 of 458
REJ09B0250-0200
R8C/20 Group, R8C/21 Group
RENESAS MCU
1. Overview
This MCU is built using the high-performance silicon gate CMOS process using the R8C CPU core and is packaged
in a 48-pin plastic molded LQFP. This MCU operates using sophisticated instructions featuring a high level of
instruction efficiency. With 1 Mbyte of address space, it is capable of executing instructions at high speed. This
Furthermore, the data flash (1 KB x 2 blocks) is embedded in the R8C/21 Group.
The difference between R8C/20 and R8C/21 Groups is only the existence of the data flash. Their peripheral functions
are the same.
1.1 Applications
Automotive, etc.
REJ09B0250-0200
Rev.2.00
Aug 27, 2008

Renesas R8C/20 Specifications

General

Architecture	R8C
CPU Clock Speed	20 MHz
Flash Memory	8 KB to 32 KB
Serial Interfaces	UART, I2C, SPI
Operating Voltage	2.7 V to 5.5 V
Core	R8C
Timers	8-bit timer x 2
ADC	10-bit
Package	LQFP
Operating Temperature	-20°C to +85°C
