RL78/G13 CHAPTER 29 ELECTRICAL SPECIFICATIONS
R01UH0146EJ0100 Rev.1.00 983
Sep 22, 2011
Caution The pins mounted depend on the product. Refer to 2.1.1 20-pin products to 2.1.14 128-pin products,
and 2.1.15 Pins for each product (pins other than port pins).
29.3.2 On-chip oscillator characteristics
(T
A = −20 to +85°C, 1.6 V ≤ EVDD0 = EVDD1 ≤ VDD ≤ 5.5 V, VSS = EVSS0 = EVSS1 = 0 V)
Oscillators Parameters Conditions MIN. TYP. MAX. Unit
32 MHz selected 31.68 32.00 32.32 MHz
24 MHz selected 23.76 24.00 24.24 MHz
16 MHz selected 15.84 16.00 16.16 MHz
12 MHz selected 11.88 12.00 12.12 MHz
8 MHz selected 7.92 8.00 8.08 MHz
4 MHz selected 3.96 4.00 4.04 MHz
1.8 V ≤ VDD ≤ 5.5 V
1 MHz selected 0.99 1.00 1.01 MHz
32 MHz selected 30.40 32.00 33.60 MHz
24 MHz selected 22.80 24.00 25.20 MHz
16 MHz selected 15.20 16.00 16.80 MHz
12 MHz selected 11.40 12.00 12.60 MHz
8 MHz selected 7.60 8.00 8.40 MHz
4 MHz selected 3.80 4.00 4.20 MHz
High-speed on-chip
oscillator clock frequency
Note
f
IH
1.6 V ≤ V
DD < 1.8 V
1 MHz selected 0.95 1.00 1.05 MHz
Low-speed on-chip oscillator
clock frequency
f
IL 12.75 15 17.25 kHz
(TA = −40 to +85°C, 1.6 V ≤ EVDD0 = EVDD1 ≤ VDD ≤ 5.5 V, VSS = EVSS0 = EVSS1 = 0 V)
Oscillators Parameters Conditions MIN. TYP. MAX. Unit
32 MHz selected 31.52 32.00 32.48 MHz
24 MHz selected 23.64 24.00 24.36 MHz
16 MHz selected 15.76 16.00 16.24 MHz
12 MHz selected 11.82 12.00 12.18 MHz
8 MHz selected 7.88 8.00 8.12 MHz
4 MHz selected 3.94 4.00 4.06 MHz
1.8 V ≤ VDD ≤ 5.5 V
1 MHz selected 0.985 1.00 1.015 MHz
32 MHz selected 30.24 32.00 33.76 MHz
24 MHz selected 22.68 24.00 25.32 MHz
16 MHz selected 15.12 16.00 16.88 MHz
12 MHz selected 11.34 12.00 12.66 MHz
8 MHz selected 7.56 8.00 8.44 MHz
4 MHz selected 3.78 4.00 4.22 MHz
High-speed on-chip
oscillator clock frequency
Note
f
IH
1.6 V ≤ V
DD < 1.8 V
1 MHz selected 0.945 1.00 1.055 MHz
Low-speed on-chip oscillator
clock frequency
f
IL 12.75 15 17.25 kHz
Note This only indicates the oscillator characteristics. Refer to AC Characteristics for instruction execution time.
When WQFN (24-, 32-, 40-, 48-pin), FLGA (25-, 36-pin), FBGA (64-pin), TQFP (64-pin), LQFP (14 × 20) (100-,
128-pin) products, these specifications show target values, which may change after device evaluation.
