Renesas RL78/G13 User Manual

RL78/G13 CHAPTER 30 PACKAGE DRAWINGS
R01UH0146EJ0100 Rev.1.00 1052
Sep 22, 2011
30.10 52-pin products
R5F100JCAFA, R5F100JDAFA, R5F100JEAFA, R5F100JFAFA, R5F100JGAFA, R5F100JHAFA, R5F100JJAFA,
R5F100JKAFA, R5F100JLAFA
R5F101JCAFA, R5F101JDAFA, R5F101JEAFA, R5F101JFAFA, R5F101JGAFA, R5F101JHAFA, R5F101JJAFA,
R5F101JKAFA, R5F101JLAFA
52-PIN PLASTIC LQFP (10x10)
y
e
xb
M
θ
L
c
HD
HE
A1
A2
A
D
E
0.145
±0.055
(UNIT:mm)
ITEM DIMENSIONS
D
E
HD
HE
A
A1
A2
10.00±0.10
10.00±0.10
12.00±0.20
12.00±0.20
1.70 MAX.
0.10±0.05
1.40
c
θ
e
x
y
0.65
0.13
0.10
L
0.50±0.15
0° to 8°
detail of lead end
0.32±0.05
b
13
26
1
52
14
27
40
39
2
1
3
P52GB-65-GBS
NOTE
1.Dimensions “ 1” and “ 2” do not include mold flash.
2.Dimension “ 3” does not include trim offset.
