RL78/G13 CHAPTER 30 PACKAGE DRAWINGS

R01UH0146EJ0100 Rev.1.00 1053

Sep 22, 2011

30.11 64-pin products

R5F100LCAFA, R5F100LDAFA, R5F100LEAFA, R5F100LFAFA, R5F100LGAFA, R5F100LHAFA, R5F100LJAFA,

R5F100LKAFA, R5F100LLAFA

R5F101LCAFA, R5F101LDAFA, R5F101LEAFA, R5F101LFAFA, R5F101LGAFA, R5F101LHAFA, R5F101LJAFA,

R5F101LKAFA, R5F101LLAFA

NOTE

Each lead centerline is located within 0.13 mm of

its true position at maximum material condition.

detail of lead end

Sxb

64-PIN PLASTIC LQFP(12x12)

0.145

+0.055

−0.045

(UNIT:mm)

ITEM DIMENSIONS

12.00±0.20

14.00±0.20

1.60 MAX.

0.10±0.05

1.40±0.05

0.25

0.65

0.13

0.10

1.125

0.50

0.60±0.15

1.00±0.20

P64GK-65-UET-1

3°

+5°

−3°

0.32

+0.08

−0.07
