RL78/G13 CHAPTER 15 DMA CONTROLLER
R01UH0146EJ0100 Rev.1.00 810
Sep 22, 2011
15.4.2 Transfer mode
The following four modes can be selected for DMA transfer by using bits 6 and 5 (DRSn and DSn) of DMA mode
control register n (DMCn).
DRSn DSn DMA Transfer Mode
0 0 Transfer from SFR of 1-byte data (fixed address) to RAM (address is incremented by +1)
0 1 Transfer from SFR of 2-byte data (fixed address) to RAM (address is incremented by +2)
1 0 Transfer from RAM of 1-byte data (address is incremented by +1) to SFR (fixed address)
1 1 Transfer from RAM of 2-byte data (address is incremented by +2) to SFR (fixed address)
By using these transfer modes, up to 1024 bytes of data can be consecutively transferred by using the serial interface,
data resulting from A/D conversion can be consecutively transferred, and port data can be scanned at fixed time intervals
by using a timer.
15.4.3 Termination of DMA transfer
When DBCn = 00H and DMA transfer is completed, the DSTn bit is automatically cleared to 0. An interrupt request
(INTDMAn) is generated and transfer is terminated.
When the DSTn bit is cleared to 0 to forcibly terminate DMA transfer, DMA byte count register n (DBCn) and DMA RAM
address register n (DRAn) hold the value when transfer is terminated.
The interrupt request (INTDMAn) is not generated if transfer is forcibly terminated.
Remark n: DMA channel number (n = 0 to 3)
