12.5.5 Slave reception
Slave reception is that the RL78/G13 receives data from another device in the state of a transfer clock being input from
another device.
3-Wire Serial I/O CSI00 CSI01 CSI10 CSI11 CSI20 CSI21 CSI30 CSI31
Target channel Channel
0 of
SAU0
Channel
1 of
SAU0
Channel
2 of
SAU0
Channel
3 of
SAU0
Channel
0 of
SAU1
Channel
1 of
SAU1
Channel
2 of
SAU1
Channel
3 of
SAU1
Pins used SCK00,
SI00
SCK01,
SI01
SCK10,
SI10
SCK11,
SI11
SCK20,
SI20
SCK21,
SI21
SCK30,
SI30
SCK31,
SI31
INTCSI00 INTCSI01 INTCSI10 INTCSI11 INTCSI20 INTCSI21 INTCSI30 INTCSI31Interrupt
Transfer end interrupt only (Setting the buffer empty interrupt is prohibited.)
Error detection flag Overrun error detection flag (OVFmn) only
Transfer data length 7 or 8 bits
Transfer rate Max. fMCK/6 [Hz]
Notes 1, 2
Data phase Selectable by the DAPmn bit of the SCRmn register
• DAPmn = 0: Data input starts from the start of the operation of the serial clock.
• DAPmn = 1: Data input starts half a clock before the start of the serial clock operation.
Clock phase Selectable by the CKPmn bit of the SCRmn register
• CKPmn = 0: Forward
• CKPmn = 1: Reverse
Data direction MSB or LSB first
Notes 1. Because the external serial clock input to the SCK00, SCK01, SCK10, SCK11, SCK20, SCK21, SCK30, and
SCK31 pins is sampled internally and used, the fastest transfer rate is f
MCK/6 [Hz].
2. Use this operation within a range that satisfies the conditions above and the AC characteristics in the
electrical specifications (see CHAPTER 29 ELECTRICAL SPECIFICATIONS).
Remarks 1. f
MCK: Operation clock frequency of target channel
2. m: Unit number (m = 0, 1), n: Channel number (n = 0 to 3), mn = 00 to 03, 10 to 13
