RL78/G13 CHAPTER 1 OUTLINE
R01UH0146EJ0100 Rev.1.00 3
Sep 22, 2011
1.2 Ordering Information
• Flash memory version (lead-free product)
(1/3)
Pin count Package Data flash Part Number
Mounted R5F1006AASP, R5F1006CASP, R5F1006DASP, R5F1006EASP 20 pins 20-pin plastic SSOP (7.62 mm
(300))
Not mounted R5F1016AASP, R5F1016CASP, R5F1016DASP, R5F1016EASP
Mounted R5F1007AANA, R5F1007CANA, R5F1007DANA, R5F1007EANA24 pins 24-pin plastic WQFN
(fine pitch) (4 × 4)
Not mounted R5F1017AANA, R5F1017CANA, R5F1017DANA, R5F1017EANA
Mounted R5F1008AALA, R5F1008CALA, R5F1008DALA, R5F1008EALA
25 pins
25-pin plastic FLGA (3 × 3)
Not mounted R5F1018AALA, R5F1018CALA, R5F1018DALA, R5F1018EALA
Mounted R5F100AAASP, R5F100ACASP, R5F100ADASP,
R5F100AEASP, R5F100AFASP, R5F100AGASP
30 pins
30-pin plastic SSOP
(7.62 mm (300))
Not mounted R5F101AAASP, R5F101ACASP, R5F101ADASP,
R5F101AEASP, R5F101AFASP, R5F101AGASP
Mounted R5F100BAANA, R5F100BCANA, R5F100BDANA,
R5F100BEANA, R5F100BFANA, R5F100BGANA
32 pins
32-pin plastic WQFN
(fine pitch)(5 × 5)
Not mounted R5F101BAANA, R5F101BCANA, R5F101BDANA,
R5F101BEANA, R5F101BFANA, R5F101BGANA
Mounted R5F100CAALA, R5F100CCALA, R5F100CDALA,
R5F100CEALA, R5F100CFALA, R5F100CGALA
36 pins
36-pin plastic FLGA (4 × 4)
Not mounted R5F101CAALA, R5F101CCALA, R5F101CDALA,
R5F101CEALA, R5F101CFALA, R5F101CGALA
Mounted R5F100EAANA, R5F100ECANA, R5F100EDANA,
R5F100EEANA, R5F100EFANA, R5F100EGANA, R5F100EHANA
40 pins
40-pin plastic WQFN
(fine pitch)(6 × 6)
Not mounted R5F101EAANA, R5F101ECANA, R5F101EDANA,
R5F101EEANA, R5F101EFANA, R5F101EGANA, R5F101EHANA
Mounted R5F100FAAFP, R5F100FCAFP, R5F100FDAFP, R5F100FEAFP,
R5F100FFAFP, R5F100FGAFP, R5F100FHAFP, R5F100FJAFP,
R5F100FKAFP, R5F100FLAFP
44 pins
44-pin plastic LQFP (10 × 10)
Not mounted R5F101FAAFP, R5F101FCAFP, R5F101FDAFP, R5F101FEAFP,
R5F101FFAFP, R5F101FGAFP, R5F101FHAFP, R5F101FJAFP,
R5F101FKAFP, R5F101FLAFP
