RL78/G13
CHAPTER 1 OUTLINE
R01UH0146EJ0100 Rev.1.00
8
Sep 22, 2011
1.3.3 25-pin products
•
25-pi
n plastic FLGA (3
×
3)
INDEX MARK
T
op View
Bottom View
5
4
3
2
1
ABCDE
EDCBA
INDEX MARK
A
B
C
D
E
5
P40/TOOL0
RESET
P01/ANI16/
TO00/RxD1
P22/ANI2
P147/ANI18
5
4
P122/X2/
EXCLK
P137/INTP0
P00/ANI17/
TI00/TxD1
P21/ANI1/
AV
REFM
P10/SCK00/
SCL00
4
3
P121/X1
V
DD
P20/ANI0/
AV
REFP
P12/SO00/
TxD0/
TOOLTxD
P11/SI00/
RxD0/
TOOLRxD/
SDA00
3
2
REGC
V
SS
P30/INTP3/
SCK11/SCL11
P17/TI02/
TO02/SO11
P50/INTP1/
SI11/SDA11
2
1
P60/SCLA0
P61/SDAA0
P31/TI03/
TO03/INTP4/
PCLBUZ0
P16/TI01/
TO01/INTP5
P130
1
A
B
C
D
E
Caution
Connect the REGC pin to
Vss via a capacitor (0.47 to 1
μ
F).
Remark
For pin identification, see
1.4 Pin Identification
.
