RL78/G13 CHAPTER 12 SERIAL ARRAY UNIT
R01UH0146EJ0100 Rev.1.00 698
Sep 22, 2011
12.8.6 Procedure for processing errors that occurred during simplified I
2
C (IIC00, IIC01, IIC10, IIC11, IIC20, IIC21,
IIC30, IIC31) communication
The procedure for processing errors that occurred during simplified I
2
C (IIC00, IIC01, IIC10, IIC11, IIC20, IIC21, IIC30,
IIC31) communication is described in Figure 12-117 and 12-118.
Figure 12-117. Processing Procedure in Case of Overrun Error
Software Manipulation Hardware Status Remark
Reads serial data register mn
(SDRmn).
The BFFmn bit of the SSRmn register
is set to 0 and channel n is enabled to
receive data.
This is to prevent an overrun error if the
next reception is completed during error
processing.
Reads serial status register mn
(SSRmn).
Error type is identified and the read
value is used to clear error flag.
Writes 1 to serial flag clear trigger
register mn (SIRmn).
Error flag is cleared. Error can be cleared only during
reading, by writing the value read from
the SSRmn register to the SIRmn
register without modification.
Figure 12-118. Processing Procedure in Case of Parity Error (ACK error) in Simplified I
2
C Mode
Software Manipulation Hardware Status Remark
Reads serial data register mn
(SDRmn).
The BFFmn bit of the SSRmn register is
set to 0 and channel n is enabled to
receive data.
This is to prevent an overrun error if the
next reception is completed during
error processing.
Reads serial status register mn (SSRmn). Error type is identified and the read
value is used to clear error flag.
Writes serial flag clear trigger register mn
(SIRmn).
Error flag is cleared. Error can be cleared only during
reading, by writing the value read from
the SSRmn register to the SIRmn
register without modification.
Sets the STmn bit of serial channel stop
register m (STm) to 1.
The SEmn bit of serial channel enable
status register m (SEm) is set to 0 and
channel n stops operation.
Creates stop condition.
Creates start condition.
Slave is not ready for reception
because ACK is not returned.
Therefore, a stop condition is created,
the bus is released, and
communication is started again from
the start condition. Or, a restart
condition is generated and
transmission can be redone from
address transmission.
Sets the SSmn bit of serial channel start
register m (SSm) to 1.
The SEmn bit of serial channel enable
status register m (SEm) is set to 1 and
channel n is enabled to operate.
Remark m: Unit number (m = 0, 1), n: Channel number (n = 0 to 3), r: IIC number (r = 00, 01, 10, 11, 20, 21, 30, 31)
mn = 00 to 03, 10 to 13
To Next Page
