RL78/G13 CHAPTER 29 ELECTRICAL SPECIFICATIONS
R01UH0146EJ0100 Rev.1.00 1032
Sep 22, 2011
Caution The pins mounted depend on the product. Refer to 2.1.1 20-pin products to 2.1.14 128-pin products,
and 2.1.15 Pins for each product (pins other than port pins).
29.6.3 On-chip debug (UART)
(T
A = −40 to +85°C, 1.8 V ≤ EVDD0 = EVDD1 ≤ VDD ≤ 5.5 V, VSS = EVSS0 = EVSS1 = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Transfer rate 115.2 k 1 M bps
29.7 Analog Characteristics
29.7.1 A/D converter characteristics
(1) When AVREF (+) = AVREFP/ANI0 (ADREFP1 = 0, ADREFP0 = 1), AVREF (−) = AVREFM/ANI1 (ADREFM = 1), target ANI
pin : ANI2 to ANI14 (supply ANI pin to V
DD)
(T
A = −40 to +85°C, 1.6 V ≤ EVDD0 = EVDD1 ≤ VDD ≤ 5.5 V, VSS = EVSS0 = EVSS1 = 0 V, Reference voltage (+) = AVREFP,
Reference voltage (−) = AV
REFM = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Resolution RES 8 10 bit
1.8 V ≤ VDD ≤ 5.5 V 1.2 ±3.5 LSB Overall error
Notes 1, 2
AINL
10-bit resolution
AV
REFP = VDD
1.6 V ≤ V
DD ≤ 5.5 V 1.2 ±7.0 LSB
3.6 V ≤ VDD ≤ 5.5 V 2.125 39
μ
s
2.7 V ≤ VDD ≤ 5.5 V
3.1875 39
μ
s
1.8 V ≤ VDD ≤ 5.5 V
17 39
μ
s
Conversion time tCONV
10-bit resolution
AV
REFP = VDD
1.6 V ≤ V
DD ≤ 5.5 V
57 95
μ
s
1.8 V ≤ VDD ≤ 5.5 V ±0.25 %FSRZero-scale error
Notes 1, 2
EZS
10-bit resolution
AV
REFP = VDD
1.6 V ≤ V
DD ≤ 5.5 V ±0.50 %FSR
1.8 V ≤ VDD ≤ 5.5 V ±0.25 %FSRFull-scale error
Notes 1, 2
EFS
10-bit resolution
AV
REFP = VDD
1.6 V ≤ V
DD ≤ 5.5 V ±0.50 %FSR
1.8 V ≤ VDD ≤ 5.5 V ±2.5 LSB Integral linearity error
Note 1
ILE
10-bit resolution
AV
REFP = VDD
1.6 V ≤ V
DD ≤ 5.5 V ±5.0 LSB
1.8 V ≤ VDD ≤ 5.5 V ±1.5 LSB Differential linearity error
Note 1
DLE
10-bit resolution
AV
REFP = VDD
1.6 V ≤ V
DD ≤ 5.5 V ±2.0 LSB
Reference voltage (+) AVREFP 1.6 VDD V
VAIN 0 AVREFP V Analog input voltage
V
BGR 2.4 V ≤ VDD ≤ 5.5 V 1.38 1.45 1.5 V
Notes 1. Excludes quantization error (±1/2 LSB).
2. This value is indicated as a ratio (%FSR) to the full-scale value.
