RL78/G13
CHAPTER 4 PORT FUNCTIONS
R01UH0146EJ0100 Rev.1.00
217
Sep 22, 2011
Figure 4-38. Blo
ck Diagram of P74
Output latch
(P74)
Alternate
function
Internal bus
P74/KR4/INTP8
WR
PU
RD
WR
PORT
PU74
EV
DD
P-ch
PU7
P7
WR
PM
PM7
POM74
POM7
WR
POM
PM74
Selector
P7:
Port register 7
PU7:
Pull-u
p resistor option register 7
PM7:
Port mode register 7
POM7:
Port output mode register 7
RD: Read
sign
al
WR
××
: Write
signal
235
237
