RL78/G13
CHAPTER 4 PORT FUNCTIONS
R01UH0146EJ0100 Rev.1.00
230
Sep 22, 2011
Figure 4-48. Block Di
agram of P102 to P106
P102/TI06/TO06,
P103/TI14/TO14,
P104/TI15/TO15,
P105/TI16/TO16,
P106/TI17/TO17
WR
PU
RD
WR
PORT
WR
PM
PU102 to PU106
PM102 to PM106
EV
DD
P-ch
PM10
PU10
P10
Output latch
(P102 to P106)
Selector
Alternate
function
Alternate
function
Internal bus
P10:
Port register 10
PU10:
Pull-up resistor option register 10
PM10:
Port mode regi
ster 10
RD: Read
sign
al
WR
××
: Write
signal
248
