RL78/F13, F14 CHAPTER 20 EVENT LINK CONTROLLER (ELC) (RL78/F14 Only)
R01UH0368EJ0210 Rev.2.10 1469
Dec 10, 2015
Table 20-2. Correspondence Between ELSELRn (n = 00 to 25) Registers and Peripheral Functions
Register Name Event Generator (Output Origin of Event Input n) Event Description
ELSELR00 External interrupt edge detection 0
INTP0
ELSELR01 External interrupt edge detection 1
INTP1
ELSELR02 External interrupt edge detection 2
INTP2
ELSELR03 External interrupt edge detection 3
INTP3
ELSELR04 External interrupt edge detection 4
INTP4
ELSELR05 External interrupt edge detection 5
INTP5
ELSELR06 Key return signal detection
INTKR
ELSELR07 RTC fixed-cycle signal/Alarm match detection
INTRTC
ELSELR08 Timer RD0 Input capture A/Compare match A INTTRD0
ELSELR09 Timer RD0 Input capture B/Compare match B INTTRD0
ELSELR10 Timer RD1 Input capture A/Compare match A INTTRD1
ELSELR11 Timer RD1 Input capture B/Compare match B INTTRD1
ELSELR12 Timer RD1 Underflow TRD1 underflow signal
ELSELR13 Timer RJ0 INTTRJ0
ELSELR14 TAU0 channel 0 Count end/Capture end INTTM00
ELSELR15 TAU0 channel 1 Count end/Capture end INTTM01
ELSELR16 TAU0 channel 2 Count end/Capture end INTTM02
ELSELR17 TAU0 channel 3 Count end/Capture end INTTM03
ELSELR18 TAU0 channel 4 Count end/Capture end INTTM04
ELSELR19 Comparator detection 0 INTCMP0
ELSELR20
Note
TAU0 channel 5 Count end/Capture end INTTM05
ELSELR21
Note
TAU0 channel 6 Count end/Capture end INTTM06
ELSELR22
Note
TAU0 channel 7 Count end/Capture end INTTM07
ELSELR23
Note
TAU1 channel 0 Count end/Capture end INTTM10
ELSELR24
Note
TAU1 channel 1 Count end/Capture end INTTM11
ELSELR25
Note
TAU1 channel 2 Count end/Capture end INTTM12
Note For Group E products only.
