RL78/F13, F14 CHAPTER 35 ELECTRICAL SPECIFICATIONS (GRADE K)
R01UH0368EJ0210 Rev.2.10 1753
Dec 10, 2015
(3) During communication at same potential (CSI mode) (master mode, SCKp … internal clock output, special
slew rate)
(TA = -40 to +125C, 4.0 V EVDD0 = EVDD1 = VDD 5.5 V, VSS = EVSS0 = EVSS1 = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
SCKp cycle time
t
KCY1 500
Note 5
ns
SCKp high-level width,
low-level width
t
KH1,
tKL1
t
KCY1
/2 – 60
ns
SIp setup time
(to SCKp)
Note 1
t
SIK1 120 ns
SIp hold time
(from SCKp)
Note 2
t
KSI1 80 ns
Delay time from SCKp to
SOp output
Note 3
t
KSO1 C = 30 pF
Note 4
90 ns
Notes 1. When DAPmn = 0 and CKPmn = 0, or DAPmn = 1 and CKPmn = 1. The Slp setup time becomes "to
SCKp" when DAPmn = 0 and CKPmn = 1 or DAPmn = 1 and CKPmn = 0.
2. When DAPmn = 0 and CKPmn = 0 or DAPmn = 1 and CKPmn = 1. The SIp hold time becomes "from
SCKp" when DAPmn = 0 and CKPmn = 1 or DAPmn = 1 and CKPmn = 0.
3. When DAPmn = 0 and CKPmn = 0, or DAPmn = 1 and CKPmn = 1. The delay time to SOp output becomes
“from SCKp” when DAPmn = 0 and CKPmn = 1, or DAPmn = 1 and CKPmn = 0.
4. C is the load capacitance of the SCKp and SOp output lines.
5. tKCY1 4/fCLK must also be satisfied.
Caution Select the normal input buffer for the SIp pin and normal output mode and special slew rate for the
SOp pin and SCKp pin.
Remark p: CSIp (p = 00, 01, 10, 11), m: Unit m (m = 0, 1), n: Channel n (n = 0, 1)
