Fusing
SM 4-99
D037/D038/D040/D041
Repla
cement
& Adjustment
4.11.16
CLEANING UNIT (OPTION) INSTALLATION
PROCEDURE
1.
Fusing unit (
Section: Fusing Unit)
2.
Fusing upper cover [A] (
x 4)
3.
T
op right frame [A] (
x 4)
4.
Install the cleaning unit [A] in the fusing unit.
268
270
