Caster Table (D488)
SM 2-27 D037/D038/D040/D041
Installaion
2.6 CASTER TABLE (D488)
2.6.1 COMPONENT CHECK
No. Description Q’ty
1 Caster Table 1
2 Pin 2
3 Step Screw 2
2.6.2 INSTALLATION PROCEDURE
1. Put the caster table on a flat place.
2. Install the two pins in the screw holes.
 Use the screw holes [A] and [C] if the mainframe is directly installed on the caster
