1. Installation
Fax Option Type M28 (D3E7-02, -03)
This option is not available for North America, because fax is built in.
Accessory Check
Check the quantity and condition of the components against the following list.
No. Description Q’ty
1 FCU 1
2 Speaker Bracket 1
3 Ferrite Core 1
- EMC Address Decal (EU only) 1
- Serial Number Decal 1
Installation Procedure
• Before doing this procedure, print out all data in the printer buffer.
• Push the operation switch to put the machine in standby mode. Make sure the power LED is off, turn the
main switch off, and then disconnect the power cord and the network cable.
• The mainframe equipped with the fax unit must be connected to a properly grounded socket outlet.
