Image/Paper Transfer
265
4. Remove the ID sensor shutter solenoid [A]. ( × 2, × 1, × 1, × 1)
Paper Transfer Roller Unit
Before Replacing the Paper Transfer Roller Unit
Before replacing the paper transfer roller unit, reset the PM counter.
1. Turn the power ON.
2. Reset the PM counter. (Refer to Replacement Procedure of the PM/Yield Parts)
3. Turn the power OFF.
Replacing the Paper Transfer Roller Unit
1. Open the right door.
• If you find paper dust on the registration section when you open the duplex unit, remove the dust.
Otherwise, the dust causes lines on the image.
To Next Page
