Ricoh D296 User Manual

Controller Options
168
2. Install the interface board [A] into the slot and then fasten it with screws.
3. Make sure that the machine can recognize the option on Web Image Monitor.
1. Start Web Image Monitor.
2. Log in as the machine administrator.
3. Click [Device Management] > [Configuration] > [Interface Setting].
4. Check that the [USB] is "Active".
Check All Connections
1. Plug in the power cord.
2. Turn ON the main power.
3. Enter the printer user mode. Then print the configuration page.
[User Tools] > [Machine Features] > [Printer Features] > [List Test Print] > [Configuration Page]
All installed options are shown in the "System Reference" column.

Ricoh D296 Specifications

General

Print Technology	Laser
Paper Input Capacity	250 sheets
Network Ready	Yes
USB Port	Yes
Paper Size	A4, A5, A6, B5, Legal, Letter, Executive
Interface	USB 2.0, Ethernet
