PM/Yield Parts Settings
175
3. Press [EXECUTE] to output the PM counter list.
Preparation before Operation Check
1. Clean the exposure glasses (for DF and book scanning).
2. Enter the user tools mode.
3. Do the "Automatic Color Calibration (ACC)" for the copier mode and printer mode as follows:
• Print the ACC test pattern (User Tools > Maintenance > ACC > Start).
• Put the printout on the exposure glass.
• Put 10 sheets of white paper on the test chart. This ensures a precise ACC adjustment.
• Close the ADF or the platen cover.
• Press "Start Scanning" on the LCD. Then, the machine starts the ACC.
4. Exit the User Tools mode, and then enter the SP mode.
5. Do the "Forced line position adjustment" as follows.
• First do SP2-111-3 (Mode c).
• Then do SP2-111-1 (Mode a).
• To check if SP 2-111-1 was successful, watch the screen during the process. A message is displayed at
the end. Also, you can check the result with SP 2-194-10 to -12.
6. Exit the SP mode.
