Scanner
239
5. Remove the brackets [A][B].
6. Remove the scanner HP sensor [B] while lifting up the bracket [A] slightly.
Scanner Motor
1. Remove the ADF unit. (ADF Unit)
2. Remove the scanner front cover. (Scanner Front Cover)
3. Remove the scanner upper cover [A].
