Image/Paper Transfer

261

3. Remove the cover [A]. ( × 2)

4. Remove the gear [A] and ITB contact motor [B]. ( × 2)

ITB Contact HP Sensor

1. Remove the drive unit. (Drive Unit)

2. Remove the ITB contact unit [A]. ( × 3, × 1)
