Fusing
284
Make sure that both side plates fit right into the locating bosses of the frame before securing the screws.
The new fusing sleeve belt assembly has a jig [A], which must be removed. Set the fusing sleeve belt assembly
first, tighten the screws, then remove the jig.
Fusing Entrance Sensor
1. Open the right door.
• If you find paper dust in the registration section when you open the right door, remove the dust.
Otherwise, the dust can cause lines on the image.
