4.Service Tables
50
Service Tables
SP1-XXX (Bit Switches)
Bit Switches
1
Mode No. Function
101 System Switch
001 – 032 00 – 1F Change the bit switches for system settings for the fax option
See "Bit Switches - 1"
102 Ifax Switch
001 – 016 00 – 0F Change the bit switches for internet fax settings for the fax option
See "Bit Switches - 2"
103 Printer Switch
001 – 016 00 – 0F Change the bit switches for printer settings for the fax option
See "Bit Switches - 2"
104 Communication Switch
001 – 032 00 – 1F Change the bit switches for communication settings for the fax option
See "Bit Switches - 3"
105 G3-1 Switch
001 – 016 00 – 0F Change the bit switches for the protocol settings of the standard G3 board
See "Bit Switches - 4"
111 IP fax Switch
001 – 016 00 – 0F Change the bit switches for optional IP fax parameters
See "Bit Switches - 5"
SP2-XXX (RAM)
2
Mode No. Function
101 RAM Read/Write
001 Change RAM data for the fax board directly. See "Service RAM
Addresses"
102 Memory Dump
001 G3-1 Memory
Dump
Print out RAM data for the fax board.
See "Service RAM Addresses"
103 G3-1 NCU Parameters
001 –
023
CC, 01 – 22 NCU parameter settings for the standard G3 board. See "NCU
Parameters"
