1.Replacement and Adjustment

5

1-Bin LED Board

1. Remove the 1-Bin tray unit. (See “1-Bin Tray BN1030” in the mainframe service manual)

2. Remove the 1-bin LED board cover [A]. ( × 1)

3. Remove the 1-bin LED board [A]. ( × 1)
