Bypass

307

3. Remove the gear [A] and bypass lift sensor [B]. (Hooks × 4)

Bypass Lift Clutch

1. Remove the bypass feed unit. (Bypass Feed Unit)

2. Remove the bracket [A]. ( × 2)
