1.
Replacement
and Adjustment
8
Friction Pad
1.
Remove the
paper feed roller
. (
Paper Feed Roller
)
2.
Remove t
he friction pad
[
A]. (
Hooks × 2,
× 1)
When reinstalling the fric
tion pad:
•
T
o prevent the f
riction pa
d from catching o
n the sheet [A], pla
ce the friction
pad while bending t
he
s
heet slightly outwar
d.
