Scanner
237
Scanner Front Cover
1. Open the right cover, and then remove the front right cover [A].
2. Open the ADF.
3. Remove the scanner front cover [A]. Use a short screwdriver.
There are five tabs on the back of the scanner front cover.
Scanner HP Sensor
1. Remove the ADF unit. (ADF Unit)
2. Remove the scanner front cover. (Scanner Front Cover)

Ricoh D296 Specifications

General

Brand	Ricoh
Model	D296
Category	Printer
Language	English
