ADF

221

3. Slide the hook [B], and then remove the white plate [C].

4. Remove the ADF registration sensor holder [A].

5. Remove the ADF registration sensor [A] from the holder.

ADF Feed Sensor

1. Remove the ADF rear cover. (ADF Rear Cover)
