Ricoh SG K3100DN User Manual

2
3
4
1
CHU097
1. Toothed rubber belt
2. Ink tubes
3. Paper pressing board
4. Feed belt
1. Open the top cover.
CHU058
2. Press the [Form Feed] key.
3. Remove the jammed paper through the top cover opening.
CHU060
When removing the paper, slowly pull it obliquely upward. Pulling it forcibly or directly upward
may cause some parts to come off.
8. Troubleshooting
230
