Ruijie Reyee RG-EG Series User Manual

Web-based Configuration Guide 1 Network Settings
78
Table 3-15 DMZ rule configuration
Parameter
Description
Name
Enter the description of the mapping rule, which is identify the DMZ rule.
Dest IP Address
Specify the IP address of the DMZ host to which packets are redirected, that is,
the IP address of the internal server that can be accessed from the Internet.
Outbound Interface
Specify the WAN port in the DMZ rule. You can configure only one rule for a
WAN port.
Status
Specify whether the rule is effective. The rule is effective after you turn on
Status.
3.15 UPnP
3.15.1 Overview
After the Universal Plug and Play (UPnP) function is enabled, the device can change the port used by the Internet
access service according to the client request, implementing NAT. When a client on the Internet wants to access
