Engineering and remote access
3.6 SITOP UPS Manager
SITOP UPS1600 / UPS1100
110 Manual, 04.2017, A5E37775406-8-76
The user interface of the SITOP UPS Manager
Tabs for selecting the submenus
Use the tab ① to reach the individual submenus.
The language selection
② is used to select the user interface language of the SITOP UPS
Manager. The German, English, French, Italian, Spanish, and Chinese languages are
available.
You use the functions of the save bar
③ to load the configuration into or from the
SITOP UPS1600 – and open or save the configurations to a data medium.
The colors of the connection lamps
④ indicate the status of the incoming and outgoing
connection. Both lamps must light green.
Left-hand connection lamp: Connection status SITOP UPS Manager application - SITOP
UPS Manager service
Right-hand connection lamp: Connection status SITOP UPS Manager service - SITOP
UPS1600
