Engineering and remote access
3.3 SIMATIC STEP 7 in the TIA Portal
SITOP UPS1600 / UPS1100
50 Manual, 04.2017, A5E37775406-8-76
Installing the Hardware Support Package (HSP)
Note
SIMATIC STEP 7 V13 service pack 1
The following s
tep is only relevant for SIMATIC STEP 7 V13 with service pack 1 in the TIA
The HSP is available at our SITOP
-homepage (http://www.siemens.com/sitop-ups1600) or
https://support.industry.siemens.com/cs/ww/en/view/75854606).
To install the Hardware Support Package, proceed as follows:
1. Start STEP 7 in the TIA Portal.
2. In the "Options" menu, click on "Support Packages".
Dialog "Detailed information" opens.
All Support Packages from the directory that you specified as storage location for Support
Packages in the settings are listed in a table.
3. You have the following possibilities to install the Hardware Support Package:
– If the Support Package is already present on your computer or on the supplied DVD,
you can add it to the list from the "Add from the file system".
– If you want to add a Support Package from the "Service & Support" page in the
Internet, download it with "Load from the Internet".
You can then add it to the file system.
4. Select the support package that you want to install.
5. Click on "Install", and follow the instructions of the installation program. During the
installation you will be prompted to close all TIA Portal instances.
6. Close all TIA Portal instances and click on "Continue".
7. After the Support Package has been installed, the TIA Portal is reinitialized by clicking on
"Restart".
The installed devices are imported into the module catalog and can then be integrated in
the project.
You can find the SITOP UPS1600 in the hardware catalog under "Power Supplies\SITOP
UPS\UPS1600".
