Engineering and remote access
3.3 SIMATIC STEP 7 in the TIA Portal
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
53
Inserting SITOP UPS1600 into a project
To be able to use the SITOP UPS1600, you must assign it as IO device to an IO controller
(SIMATIC S7 control). Further, SITOP UPS1600 can be equipped in the project with one or
several SITOP UPS1100 battery modules.
The main views used to configure the SITOP UPS1600 are the Network view and the Device
view.
Note
Additional information on the Network view and Device view, as well as the Topology view is
available in the manual for your STEP 7 software.
● The hardware support package or the general station description file of the
SITOP UPS1600 has been installed.
● STEP 7 in the TIA Portal has been opened, and a project with an IO controller (SIMATIC
S7 control) has been created.
Inserting SITOP UPS1600 from the hardware catalog
1. Open the network view.
2. Open the "Hardware catalog" task card.
3.
If you use the SITOP UPS1600 with the hardware support package:
In the "Catalog" palette, navigate to SITOP UPS1600 under Power Supplies\SITOP
UPS\UPS1600.
4.
If you use the SITOP UPS1600 with the generic station description file:
In the "Catalog" palette, navigate to the SITOP UPS1600 under "Other
devices\PROFINET IO\I/O\Siemens AG\UPS1600".
