Engineering and remote access
3.6 SITOP UPS Manager
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
113
Options of establishing a connection to the SITOP UPS1600
Depending on the type, the SITOP UPS1600 provides either a USB interface or an Ethernet
interface.
Depending on the type, the SITOP UPS1600 communicates via USB or Ethernet with the
SITOP UPS Manager.
The SITOP UPS Manager supports the master-slave operation only for an existing Ethernet
connection. This permits, for example, a controlled shutdown of the computers in the
network by the applications started with the SITOP UPS Manager.
Establishing a connection via Ethernet
The SITOP UPS1600 requires an IP address for communication with the UPS Manager. This
is assigned by the network administrator. Use the Primary Setup Tool to configure the
SITOP SITOP UPS1600 interface.
Configuring the SITOP UPS1600 with the Primary Setup Tool
The Primary Setup Tool is a Siemens product that is free of charge, and which is used to
identify and configure network-capable devices. You can download the Primary Setup Tool
at (http://support.automation.siemens.com/WW/view/en/19440762
).
From SW Version V2.1.0, the Primary Setup Tool is already integrated in the UPS Manager
(from Version V4.71.x).
The following procedure is then required:
● "Device configuration" tab
● Select network adapter
● Device configuration → DC-UPS → Update list
Additional information is contained in the Primary Setup Tool manual. This manual and
further links can be found at
(http://support.automation.siemens.com/WW/view/en/19440762
).
● The SITOP UPS1600 is connected with the client (PG/PC) via the Ethernet interface.
● The Primary Setup Tool is installed on the client.
● Firewall settings that are necessary:
– Communication via 5000 is permitted.
– Echo request (ping) is permitted.
