3.5 Cyclic and acyclic data
SITOP UPS1600 / UPS1100
90 Manual, 04.2017, A5E37775406-8-76
3.5
Cyclic and acyclic data
The data communicated between SITOP UPS1600 and the PROFINET IO-Controller can be
viewed in SIMATIC STEP 7 or SIMATIC STEP 7 in the TIA Portal. Here, a distinction is
made between cyclic data (input/output data) and acyclic data (reading/writing data sets).
Input/output data
SITOP UPS1600 sends, in cyclic intervals (1 ms - 512 ms for IRT or 1 ms - 2048 ms for RT),
data about the actual operating states to the PROFINET IO-Controller. You will find more
information on this at Input and output data (Page 90).
Reading and writing data sets
Reading and writing data sets are sent acyclically from the SITOP UPS1600 to the
PROFINET IO-Controller or from the PROFINET IO-Controller to the SITOP UPS1600.
Additional information can be found at Reading and writing data sets (Page 91).
3.5.1
Input and output data
An overview of the input and output data, which is cyclically sent from the SITOP UPS1600
to the PROFINET IO controller is provided in the following tables.
Slot
Subslot
Data
Description
Data size
0 2 Input voltage Input voltage is present:
• 0: NOT OK
• 255: OK
Unsigned8
Buffer mode Buffer mode:
The load connected to the
SITOP UPS1600 is supplied via
the energy storage device con-
nected to the SITOP UPS1600:
• 0: inactive
• 255: active
Unsigned8
Ready for buffering Ready for buffer operation as the
energy storage device of the
buffer component has been suffi-
ciently charged.
• 0: NOT OK
• 255: OK
Unsigned8
Charge sufficient Charge level sufficient: When this
flag is set, the required charge
level has been achieved:
• 0: NOT OK
• 255: OK
Unsigned8
