Siemens 6EP4134-3AB00-2AY0 User Manual

Technical data
8.1 Input data
SITOP UPS1600 / UPS1100
212 Manual, 04.2017, A5E37775406-8-76
8.1.2
SITOP UPS1100
Charge current
● The charge current is limited by the maximum permissible charge current of the UPS1600
(see Chapter SITOP UPS1600 (Page 213))
● When a battery module is connected, the charge current is max. 0.3C A.
● For several battery modules connected in parallel, the max. charge current is 0.3C A
multiplied by the number of batteries connected in parallel.
Recommended end-of-charge voltage (standby use), dependent on the battery temperature
6EP4131-0GB00- ... (1.2 Ah)
6EP4133-0GB00- ... (3.2 Ah)
6EP4134-0GB00- ... (7 Ah)
6EP4135-0GB00- ... (12 Ah)
6EP4132-0GB00- ... (2.5 Ah)
6EP4133-0JB00- ... (5 Ah)
At -10 °C
-
29.0 V
29.28 V
At 0 °C
-
28.6 V
29.52 V
At 10 °C
27.8 V
28.3 V
29.16 V
At 20 °C
27.3 V
27.9 V
28.8 V
At 30 °C
26.8 V
27.5 V
28.8 V
At 40 °C
26.6 V
27.2 V
28.8 V
At 50 °C
-
26.8 V
27.8 V
At 60 °C
-
26.4 V
-
Note
Battery module UPS1100 5
Ah with LiFePo batteries can only be used in conjunction with
UPS1600 from software version V
2.1 and higher.
See also
SITOP UPS1600 (Page 213)
Output data (Page 213)
