Siemens 6EP4134-3AB00-2AY0 User Manual

SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
183
Troubleshooting
4
You can obtain additional information on an active alarm from the help text.
The extended error type is used to interpret alarms in S7 function blocks that you have
programmed yourself.
The severity indicates the severity of the alarm:
● D = diagnostics
● MD = Maintenance Demanded
● MR = Maintenance Required
● F = Failure (module has failed)
Error
Type
Ex-
tended
Error
Type
Severity
Alarm Text
Help Text
256
1
F
Software corrupted
Software is corrupt - try to update the software
256
2
MR
Wrong checksum
Internal error: Communication disrupted
256
3
MR
Parameter corrupt
Attempting to write to an unknown or read-only object.
256
4
MR
Unknown parameter
Attempting to set a parameter that is not known by UPS1600.
256
5
MR
Wrong message length
Internal error: Communication disrupted
256
6
MR
Wrong parameter
Parameter value is not within the specified range
256
7
MR
Command not accepted
An incorrect command was sent to the UPS1600
256 8 MR Communication error:
Wrong length field
Syntax error in command
256
9
MR
Wrong request
Error in sent message: Unknown request sent.
256
10
MR
Cannot write to object
Attempting to write a parameter that is "read-only"
256
11
MR
Object pending
UPS1600 cannot provide data for the requested object.
256 12 MR Battery not available Attempting to access a battery that is not available. Either the
battery with the requested number was never connected or
communication with this battery was interrupted.
256
13
MR
EEPROM write error
Saving UPS1600 parameters failed. Device is defective.
256
14
MR
Unknown alarm
Internal error: Wrong parameter at execution of test command.
256
15
MR
Command outside range
An incorrect command was sent to the UPS1600
256 16 MR Software update is being
performed
The command sent cannot be executed as long as the pro-
gram is running.
256 17 MR No software update Cannot execute the sent command because no software up-
date has been started.
256 18 MR Wrong battery number Attempting to retrieve data about a battery which does not
exist or is not connected.
256 19 MR Wrong address Wrong Flash address in software update - software update file
is corrupt.
