Engineering and remote access
3.6 SITOP UPS Manager
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
119
Note
When saving or loading a HW configuration, the entry in "Base unit > Location" is not
accepted/changed.
3.6.7.1
General settings
Under "Software configuration > General settings", specify the maximum size of the log file in
Kbytes and where it is saved.
From SITOP UPS Manager V4.12.5 and higher, under "Software configuration > General
settings" you can also specify as to whether the window of the SITOP UPS Manager should
always be in the foreground.
Log file
1. Select "Software configuration > General settings".
2. Enter the maximum file size in kbytes in the "Size of log file" dialog box.
3. Click on "Browse"
4. Select the directory in which the log file should be stored.
5. Confirm with "Select folder".
The maximum size and the storage location of the log file has been saved.
3.6.7.2
Configuring the SITOP UPS1600
Using the SITOP UPS Manager, you can configure the SITOP UPS1600 and its energy
storage device, and then load to the device (if it is an uncoded battery – for UPS1100, the
values are automatically identified). To change the charge parameters switch-in threshold or
buffer time, you must set the corresponding rotary coding switch to the "REN" position.
1. To do this, select "Hardware configuration > Base device" or "Hardware configuration >
Energy storage".
2. Enter the desired values.
3. Click on "Download"
Configuring the basic device (base unit)
The following parameters are available under "Hardware configuration> Base unit".
Parameter
Value range
Default setting
Location
Free text
–
Connection threshold
21 - 25 V
22.5 V
Buffer time
1 - 32767 s
600 s
Maximum buffer time
1)
Yes / No
No
